4600-350B2 ELIMINATOR II
For Eurocopter Model AS350B1, B2 and B3 Helicopters
Isolair is a world leader in the manufacture and distribution of the medium-lift
capacity fire-fighting tank system, supplying such models as the Eurocopter Air Bus.
System Components
- Tank Assembly: External belly-mounted fiberglass and aluminum tank mounted to aircraft cross tubes. Tank attaches with quick-release pins for fast and easy installation.
- Refill Pump: Electrically driven pump and hose assembly with in-flight emergency release capability.
- Dump Doors: Electrically actuated, hydraulically operated. Fail safe system; doors will open with the loss of electrical power.
- Cyclic Control: Allows pilot to control loading, mixing, dump volume and drop length.
Specifications
| Net Weight | 330 lbs. |
| Gross Weight | 2537 lbs. |
| System Capacity | 270 gallons |
| Chemical Capacity | 15 gallons |
| Amperage Draw (refill) | 90 amps |
| Power Requirements | 24VDC |
| Hover Fill Rate (max) | 270 GPM |
| Hover File Time (probe submerged) | 50-60 secs. |
| VNE (water drop) | 80 knots |
| VNE (tank empty, pump stored) | 100 knots |
